16 L Agriculture

Service Title: 16L Agriculture Spraying & Seed Spreading Drone

Description:

AGRI KRANTHI 16L is a powerful and efficient agricultural drone designed for large-scale farming operations. With increased payload capacity and optimized performance, this drone enables faster crop spraying and seed spreading with precision. Built with advanced navigation, safety features, and intelligent flight control, it ensures reliable and efficient agricultural operations in diverse environments.

Key Features:

• Auto spray & seed spreading system
• 16L high-capacity payload
• Advanced flight controller & navigation
• Smart failsafe & return-to-home system
• Designed for medium to large farms
• Efficient and time-saving operations

Technical Specifications:

🔹 Physical & Performance

• Maximum Take-off Weight: 37 Kg
• Endurance: Up to 15 minutes (with payload)
• Range: 1 KM (VLOS)
• Max Operating Altitude: 20m AGL
• Operating Temperature: 0°C to 50°C
• Wind Resistance: Up to 8 m/s
• Max Speed: Up to 8 m/s
• Battery: 22000mAh × 2 (6S LiPo)

🔹 Flight & Operation

• Launch Type: Vertical Take-Off & Landing (VTOL)
• Flight Modes: Auto Spray, RTL (Return to Launch)
• Propulsion: Electric propulsion system

🔹 Safety Features

• Return-to-home on communication failure
• Low battery warning at 30%
• Auto return at 20% battery
• Geo-fencing capability
• Altitude restriction (max 20m AGL)

🔹 Ground Control System (GCS)

• Controller: Skydroid H12 Display
• Frequency: 2.4 GHz (Up & Down Link)
• Functions:
  • Flight planning & waypoint navigation
  • Real-time telemetry display
  • Battery & distance monitoring
  • Artificial horizon display

🔹 Additional Features

• Pre-flight checklist system
• Telemetry data logging
• Google Maps integration
• Dynamic mission adjustment

🔹 Operational Details

• Crew Requirement: 1–2 persons
• Packaging: Standard casing with peripherals

🔹 Support & Compliance

• DGCA guideline support
• Technical troubleshooting support
• Warranty: 1 Year
